Single Girder EOT Crane

Single Girder EOT Crane
Single Girder EOT Crane
Send Inquiry
Product Code : 03
Price And Quantity
  • Minimum Order Quantity
  • 1 Piece
  • Price Range
  • 500000.00 - 5000000.00 INR/Piece
Product Specifications
  • Crane Type
  • Eot
  • Lifting Capacity
  • 5-10 ton Long Ton
  • Lifting Height
  • 40-60 feet Foot (ft)
  • Emergency Stop
  • Yes
Product Description

It has been recognized and reputable since the year 1991, we are considered as one of the most trusted organizations which is engrossed in manufacturing, exporting and supplying superior and premium quality of the Single Girder EOT Crane. These cranes are designed and engineered in conformity with all primary and essential set of laws and policies of this industry. In addition to this, we make certain that our presented cranes are put together or assembled at our customers ends within pre set time frame. In addition to the above mentioned pointers, the Single Girder EOT Crane provided by us is acknowledged and accredited for the following quality features:

  • They are quite Low in noise
  • They have a steady and stable running
  • It has Optimum effectiveness

Other Details:

Single Girder E.O.T Crane:

These SAFEX Single Girder and Double Girder E.O.T Cranes are fabricated, engineered & manufactured in accordance with the international standard IS : 3177 and IS : 4137 taking into consideration sufficient factor of security with respect to suitable and apt duty categorizations. The structural parts of the cranes are fabricated in conformity with the international standard IS : 807. in addition to this, Safex also produces cranes as per the much accepted global standards. These Safex cranes are produced with regular components and control systems to make sure optimum consistency and dependability.

Signle Girder Type E.O.T. Cranes has the following features:

  • Its Span ranges from : 3 meters  to 30 meters
  • The secure and protected Working Load varies from : 500 kgs to 20,000 kgs
  • Crane Control: From floor all the way through the Pendant Push Buttons, alternatively through Radio Remote Control OR the cabin with master control
  • Power Supply System : To lift and Cross Travel all the way through Trailing Cables OR Drag Chain To Crane all the way through Shrouded Bus Bars OR Trailing Cable OR MS Angle Iron Conductors OR Bare Copper Conductors (which can entirely depend on the clients choice and application)
  • Motors : the Squirrel Cage & Slip ring Motors is on the basis pf the application needs, integrated and fixed separator which are electrically activated fail safe brakes for all 3 motions. The Motors with F class insulation are offered in all the motions.
  • Drive System : it is designed in accordance with the international standard IS : 3177 Structural Parts along with the international standard of IS : 807, and Other varied and diverse Parts with the following international standard i.e. IS : 3177, IS : 3938 and IS : 4137
  • Speeds : it is chosen and preferred based on the client requirements / applications OR shed dimensions.
  • Class of Duty OR Standards : it is alike to M3, M5, M7, M8 as per the international standard IS 3177 OR IS 807
Trade Information
  • FOB Port
  • ex- works Ahmedabad
  • Supply Ability
  • 2 Piece Per Month
  • Delivery Time
  • 8 Week
  • Main Domestic Market
  • Maharashtra


We mainly deal in Mumbai,Maharashtra,Pune and Gujarat...
